Upload alarm information when the main power is disconnected
Data upload
Update GPS data in real time and support customization
Geo fence
TBD
Driving behavior detection
When the vehicle speed exceeds the set speed, the device will upload the over-speed alarm
GPS data
Real-time location updates
Vibration alarm
Vehicle vibration report in armed state
Called-and-listened-for function
N/A
4.Basic Product Function
Use
Function
Description
GPS tracking and locating
4G network
Supporting 4G network, 1 second efficient transmission, faster and more accurate
Timing tracking
Reporting positioning information such as latitude and longitude according to the set interval
Over-speed alarm
The tracker will send an alarm to your mobile phone when driving speed is too fast
Vibration alarm
Built-in vibration sensor, when the vehicle vibrate continuously, the device will immediately send an alarm information
Geo fence
when the driving range of the car exceeds the specified area, an alarm message will be sent to the platform
Historical track
The platform can play back of history driving route, including speed, direction and stay time, etc.
Displacement alarm
When the vehicle is being illegal operation or being theft, users can remotely cut off the oil and electricity through the computer or mobile APP
Fleet management
One account can monitor multiple devices, or one device can be monitored by multiple accounts
5.Analysis and Troubleshoot of Common Problems
If the yellow light and blue light of this product are always on and do not flash, it means that the device is normal online positioning. In case of flashing, please follow the following steps to analyze and troubleshoot.
Trouble
Analysis
Solution
Blue light flashing slowly
Whether to use the device in areas with poor GPS signals, such as near high-rise buildings or underground parking lots
Drive the vehicle to the position with good signal and reinstall the device
Whether the front windshield of the vehicle is pasted with metal heat insulation film, which affects the signal reception
If there is a film, use the device in another vehicle to test whether the blue light is always on. If there is no problem in testing on other vehicles without film, it is caused by the film of the vehicle
Whether there are shields or signal jammers on or around the vehicle
If there is a shield or signal jammer, remove the shield or signal jammer and try to reinstall the device
Blue light flashing quickly
Chip failure
Return to factory for maintenance
Yellow light flashing quickly
Whether the SIM card is installed properly
Make sure the SIM card is installed correctly
Whether the metal surface of SIM card has dirt or poor connect
Wipe the metal chip surface with a clean cloth or repeatedly insert and remove the card several times
Yellow light flashing slowly
Whether the vehicle is in a place without network, such as an underground parking lot
Please drive the vehicle to a place with good network signal and try to reinstall the device
Whether the server platform is normal
Ask background management whether the platform server is working normally
Whether the SIM card status is normal
Check whether the card status is normal through the SIM card query platform
Whether there are shields or signal jammers on or around the vehicle
If there is a shield or signal jammer, remove the shield or signal jammer and try to reinstall the device
6.Product Precautions
Please pay attention to waterproof of electronic products.
Please insert the SIM card before installation to ensure that the SIM card has no password, otherwise the device will not work properly.
The USB port on the terminal device is dedicated for factory testing, and it is not a device charging port. Do not use it for charging or other purposes.
There must be no substance absorbing electromagnetic wave (such as metal, explosion-proof insulating film) above the installation position.
Do not touch the devicewith liquid or operate it with wet hands.
Do not put the deviceinto fire.
The devicemay not work when the temperature is lower than – 20 ℃ or higher than+60 ℃.
When the vehicle is in the underground parking lot, tunnel or garage, the positioning signal will be affected. And there may be blind areas of communication network signals, which may cause the deviceto be unable to monitor; When the vehicle drives out of the above area, the device will automatically resume normal operation.
In case of abnormal conditions, please do not repair by yourself. The manufacturer shall not be liable for any damage caused by connecting non original accessories or unplugging the connections between components.
This product is an auxiliary product for safe driving, and any loss caused by failure or information loss has nothing to do with our company.
This product has passed the international CE certification, but because of the complex electromagnetic environment in the vehicle, this product may have electromagnetic interference with the electrical equipmentin some vehicles.
Do not install or operate this product when the vehicle is running.
Do not connect the device to uninterruptible power supply without authorization, or it may cause vehicle or product failure. Please consult with a professional about installation.
Do not shockor throw the product violently, so as to avoid damaging the product, which may lead to malfunction or failure to use.
The temperature range for normal use of this product is – 20 ℃ to 65 ℃. Exceeding this temperature range may lead to product failure,on fire or explosion.
7.After-sale Service
This product is guaranteed to be replaced for three months and guaranteed for one year from the date of shipment. During the warranty period, if the deviceis damaged due to non-human factors or product quality, please contact the dealer in a timely manner.
There is no free repair service for the damage caused by the customer’s unauthorized dismantles or alters or force majeure (such as flood and vehicle accident).
After the warranty period expires, the cost of repair materials shall be charged for the product damage and failure caused by use.
It provides customers with consulting and technical services such as purchasing, using and installing APP for free.
8.Legal statement:
First of all, thank you for using this product. If you have agreed to the following terms, you will receive our support and services. When you have doubts about this, please call for consultation. If you cannot accept the following terms, please stop using this manual.
The ownership of this manual belongs to the distributor. Any rights that not expressly granted in this manual are reserved. Without the prior written permission of the distributor, no company or individual shall copy, transmit, distribute, use or disclose the product information in the manual and any pictures, forms, data and other information contained in the manual.
Without the distributor’s prior written consent, reading this document does not imply to grant the reader any right to use any mark appearing in this document.
The storage and use of this product shall comply with the requirements of the product manual, relevant contracts or relevant laws and regulations.
The distributor reserves the right to modify and improve the products described in this manual without prior notice; At the same time, we reserve the right to revise or withdraw this manual at any time. If there is any ambiguity in the user manual, please consult the agent and seller in time.
9.Special statement:
This product is only used for anti-theft of vehicles, and it is prohibited to use it for illegal purposes, otherwise all legal liabilities arising therefrom shall be borne by the user.
